1. The development of product is carried out with rigorous mechanical engineering development accreditation standards; all products are passed the accreditations such as cold & impact test in depth, high temperature & severe cold condition test and crankshaft fatigue test etc.; External characteristic maximum torque is 2150N.m.
2. The development is strictly by European famous companies developing program, Based on the European engine development requirements, the engine overhaul period is more than 12000 hours.
1. Optimized fuel injection pump, fuel consumption better than the engines of same power
2. Four-valve technology increases the flow areas of air by a wide margin, so as to realize better atomization condition and more intense combustion.
3. Use the valve seal, With Yuchai proprietary piston ring seal technology and valve seal technology, lubricating oil consumption is lower than domestic power transmission products with more than 50%;
1. Equipped with digital intelligent local panel and remote monitoring instrument and integral cast iron freshwater cooling water jacket exhaust pipe (YC6MK Partial optional) are adopted to lower the temperature of cabin and ensure safe operation
2. Equipped with integral gearbox , rear positioned gear chamber and advanced point-line gear-meshing technology are adopted to lower mechanical noise of transmission system in further
| Model | YC6MJ365L-C20 | YC6MJ410L-C20 | YC6MJ450L-C20 |
| Number of cylinders-Bore × Stroke（mm） | 6×131×145 | ||
| DisplacementL | 11.73 | ||
| Number of valves per cylinder | 4 | ||
| Intake way | Turbo-charged& inter-cooled | ||
| Continuous power /speed(kW（Ps）/r/min) | 267（365）/1500 | 300（410）/1800 | 330（450）/2100 |
| One-hour power/speed(kW（Ps）/r/min) | 293.7（400）/1548 | 330（450）/1858 | 363（495）/2168 |
| Min. specific fuel consumption(g/kW.h) | ≤198 | ||
| Certificate | ZC、CCS、EIAPP、国一 | ||
| Overall dimensions (LxWxH)（mm） | 1834×1028×1278 | ||
| Net mass（kg） | 1200 | ||
