  • Fuel economy:
    Four-valve per cylinder technology ensure more intense combustion; lower fuel consumption, flat performance curve and wider economy working area.
  • High adaptability
    Starter configuration, single starter starting power.
  • High reliability
    Special reinforced body, low vibration, high strength, safety factor increased by 20%!
  • High adaptability
    High level fuel filter, three-stage high-efficiency environmental protection filter element, good oil adaptability, lower maintenance cost and more convenient.
  • High comfort
    High efficiency fan and multi wedge belt are used, and NVH performance is superior.
  • High reliability
    The crankshaft is made of 42CrMo material. After strict simulation calculation and optimization, the crankshaft is strengthened and the transmission capacity is improved.
  • Maintenance convenience
    The filter element of side extraction oil filter collector is convenient for maintenance
YC6TD
Diesel Engine
765-950Ps Power Coverage
Adapted Models：36-45m ³/ 2MPa air compressor, 100t mine car, locomotive, integrated drilling rig, etc
Inquiry Now
Product Advantages
High economy

Four-valve per cylinder technology ensure more intense combustion; lower fuel consumption, flat performance curve and wider economy working area.

Strong Power

High efficient Turbocharged &Inter-cooled technology, higher power per liter, larger torque, sufficient power reserve, which is applicable to various working conditions with high operation efficiency.

Safe and reliable

B10 has a service life of more than 15000 hours.

Easy maintenance

Modular design, wet cylinder liner, one cylinder one cover, side window on cylinder block, easy installation and maintainance

Low maintenance cost

Vertical structure, compact size, simple structure and convenient maintenance; There are more than 30000 platform models in the market, with high generalization of parts and low maintenance cost; Independent ECU control system, faster vehicle function development; Performance, electric control development, short solving cycle and low cost; Faster response to vehicle testing and market service.

Application Scenarios
Technical Parameters
ModelYC6TD765-T300YC6TD800-T300YC6TD950-T300
Number of cylinders, Bore×Stroke (mm)6-152×1806-152×1806-152×180
Displacement L19.619.619.6
Number of valves per cylinder444
Air inlet modePressurized intercoolingPressurized intercoolingPressurized intercooling
Rated power / speed kW/r/min561/1900588/1800700/1800
Maximum torque / speed N.m/r/min3600/1200～15003600/1200～15003800/1200～1500
Low speed torque / speed≥2800/1000≥2800/1000≥2800/1000
Emission levelGB20891-2014 Phase Ⅲ Emission Standards
Emission technology routeCR
External characteristic minimum fuel consumption g/kW.h≤190≤190≤190
Oil change interval500h500h500h
